What is a pulse testing machine?
In the fields of industrial manufacturing, materials science and electronic equipment testing, the pulse testing machine is an important testing equipment. It evaluates the performance of materials or products under extreme conditions by simulating pulse signals or impact loads. This article will introduce in detail the definition, application scenarios, technical parameters and popular models of the pulse testing machine to help you fully understand this equipment.
1. Definition of pulse testing machine
Pulse testing machine is a testing equipment used to simulate pulse signals or impact loads. It is mainly used to test the withstand ability of materials, components or complete products under transient high voltage, high current or mechanical impact. Its core function is to apply instantaneous energy to the object under test through controllable pulse waveforms (such as square waves, sine waves, sawtooth waves, etc.) to verify its reliability.
2. Main application scenarios
| Application areas | Test content |
|---|---|
| Electronic components | Surge current test, ESD immunity test |
| Electrical equipment | Insulation material withstand voltage test, circuit breaker breaking capacity |
| Automobile industry | Battery pack impact test, wire harness transient response |
| Aerospace | Impact resistance of composite materials |
3. Comparison of technical parameters (popular models)
| Model | maximum voltage | Maximum current | pulse width | Application areas |
|---|---|---|---|---|
| PT-5000X | 50kV | 10kA | 1μs-100ms | Electrical equipment |
| IMP-200 | 20kV | 5kA | 100ns-10ms | Electronic components |
| PulseMaster 3 | 30kV | 8kA | 500ns-50ms | New energy vehicles |
4. Industry hot trends (last 10 days)
1.Demand for new energy vehicle testing surges: With the popularization of 800V high-voltage platforms, the demand for pulse testing machines has grown significantly in reliability testing of battery packs and electric drive systems.
2.Third generation semiconductor test standards updated: The high-frequency pulse endurance test of SiC/GaN devices has become the focus of the industry, and the purchase volume of related testing machines has increased by 35% year-on-year.
3.Smart grid construction promotion: The State Grid’s new procurement plan includes 200 high-voltage pulse testing machines for performance verification of smart circuit breakers.
| hot events | Associated devices | Scope of influence |
|---|---|---|
| Revision of national standards for new energy vehicles | Multi-axis pulse test system | vehicle manufacturer |
| Semiconductor localization accelerates | Nanosecond pulse generator | chip design company |
5. Precautions when purchasing
1.Waveform accuracy: Key parameters include rise time (≤1% error) and pulse width stability (±2%).
2.Security protection: Need to have overcurrent protection, emergency braking and insulation monitoring functions.
3.Expansion capabilities: Models that support multi-channel synchronous testing are more suitable for future needs.
4.Data collection: The sampling rate should be ≥100MS/s, and the storage depth should be ≥1M points.
6. Future development trends
1.Intelligent upgrade: AI algorithms begin to be applied to automatic optimization of pulse waveforms and fault prediction.
2.Multiphysics coupling testing: New equipment that combines thermal-electricity-force synchronous monitoring functions has become a research and development direction.
3.standardization process: The new standards of the IEC 61000-4 series will promote the iteration of test equipment.
Through the structured data display in this article, you can clearly understand the technical characteristics and market dynamics of pulse testing machines. When selecting equipment, it is recommended to combine specific test requirements and refer to the latest industry standards for configuration selection.
